Voltizo Industries - 3kva 24v Lithium Inverter | Ups | Compact Black Design,

1. Dual source of charging from Solar Power as well as from Grid Power.
2. Power card with inbuilt PWM based solar charge controller of 50A for maximum utilization of solar power.
3. Intelligently selection of battery boost voltage to avoid un-necessary heating of battery during charging.
4. Intelligently selection of battery low shutdown for longer backup according to load conditions.
5.Regular priority of Solar Power to give maximum benefits from solar energy to run the load or charge the battery.
6. 30% AVR function below 180V Grid Input.
7. All selection switch on front side, no switch at back side.
8. Storage of Solar Power consumed from the day of installation.
9. CC & CV mode for every 0.1V increment of battery voltage.
10.Priority to maintain gravity of battery in CV mode with different time zone at regular interval of time.
11.Maximum usage of Solar Power to minimize the electricity bill and being eco-friendly.
12.Display maximum and useful parameters on LCD according to customer needs.
13.Pure Sine Wave output with less harmonic distortions.
14.Battery low cut off and overcurrent sensing with auto retries.
15.Double stage MOSFET over current protection at priority.
16.Thermal trip with auto recovery.
17.Reverse current protection from battery to solar in absence of solar power.
18.Grid Power utilization according to presence of Solar Power.
19.Critical parameters setting according to battery & grid conditions.
20.Upgradable to IOT functioning.

DISPLAYING PARAMETERS ON LCD

Model VA & Capacity Battery Voltage PV Charging Current Grid I/P Voltage Grid Charging Current AC Output Voltage Discharging Current Load Percentage Mode UPS/Normal Battery Status PV Status Grid Status Load Status Consumed PV Power Instant PV Power Thermal Trip PV Reverse Short-circuit Battery Low/High Grid MCB/Fuse Trip Battery Overload Trip

PROTECTIONS

Thermal Trip | Battery High/Low | Short-Circuit | PV Reverse | Grid MCB/Fuse Trip | Overload Trip

CRITICAL PARAMETERS SETTING PROCESS

Parameter (Per Battery)Default ValueMin - Max RangeBattery Boost Voltage14.4V13.8V “ 14.5VBattery Low Cut Off Voltage10.2V10.0V “ 11.0V

Grid Charging Current 0A-15A

1. Long press of High/Low Charging switch until LCD shows "Set Battery".
2. Press switch Auto for increment & UPS/Normal for decrement the value of Boost Voltage if required.
3. Press High/Low to change next parameter.
4. Repeat step 2&3 for Battery Low Cut & Grid Charging Current Parameter.
5. Press High/Low to save parameters and EXIT from the same switch.

PRIORITY OF SOLAR POWER AS PER GRID POWER

1. If PV Current < 8A, battery will charge from Solar as well as from Grid.
2. If PV Current is between 12A-16A, Grid will be bypassed but no charging.
3. If PV Current > 20A, Grid will be cut by PV till battery voltage below 11.8V.
4. If PV Current > 3A & Batt Volt > Boost Volt, Grid will be cut by PV & load on battery.
